AC & DC Power Distribution

Is a power distribution unit utilized for the connection of user
equipment to a single or multiple PowergridM UPS System.

High-performance AC & DC Power Distribution Units

The AC and DC Power Distribution Units Provide the Connect and Power Distribution Components for the Attachment of User Equipments to Single or Stacked Power Systems, the Consolidation and
Distribution of Primary Power Input Connections, and the Connection of Multiple Battery
Expansion (BXM) Modules to Either Single or Stacked UPS Modules.

AJPS has been supplying high end custom power solutions to the Navy, Air Force, Army, Marines,
and Coast Guard for over 20 years. Contact us to get started today, or

PowergridM AC & DC Power Distribution Features | Ruggedized UPS – Ruggedized Uninterruptible Power Supply.

Remote Power Interconnect Standard

P/N: PG-RPIM-STD:
Standard single UPS Power Distribution Unit – Single MIL Circular Input Power Connection with eight (8) NEMA 5-15P user connections – one (1) primary PDU Breaker.

Remote Power Interconnect LBI

P/N: PG-RPIM-LBI-STD:
Standard multiple UPS Power Distribution Unit – Four (4) MIL Circular Input Power Connections, one (1) PDU daisy chain MIL Circular connector, six (6) NEMA 5-15P user connections – one (1) primary PDU Breaker.

Remote Power Interconnect Modified

P/N: PG-PDU-AC-6C13
Modified single UPS Power Distribution Unit – Single MIL Circular Input Power Connection with six (6) IEC C13 Locking user connections – six (6) individual user connection Breakers (on rear of unit).
P/N: PG-PDU-AC-5015:
Modified single UPS Power Distribution Unit – Single MIL Circular Input Power Connection with six (6) MIL Circular 3-Pin user connections – six (6) individual user connection Breakers (on rear of unit).

VAC Power Distribution Unit

P/N: PG-PPC-PDB-5P:
Standard AC Power Distribution Unit – Single MIL Circular Input Power Connection with four (4) MIL Circular 3-Pin VAC connections – four (4) individual AC connection Breakers.

DC Power Distribution Unit – Battery Cell

P/N: PG-BXM-PCB-5P:
Standard DC Power Distribution Unit – Dual single ought MIL Circular Input/Output Power Connection with four (4) MIL Circular 2-Pin DC connections – four (4) individual DC connection Breakers.
P/N: PG-BXM-PCB-11P:
Modified DC Power Distribution Unit – Dual MIL Circular single ought Input/Output Power Connections (+/-) with ten (10) MIL Circular 2-Pin VDC connections – ten (10) individual VDC connection Breakers.

High-performance AC & DC Power Distribution. Get started today! Lear more about Ruggedized UPS – Ruggedized Uninterruptible Power Supply.

To learn more about our High-performance AC & DC Power Distribution, please do not hesitate to call our office today at (813) 996-2583 or Contact us by email.
